Multiple Cores Pneumatic Wire Stripping Machine Semi Auto 49kg-115kg Force

Multiple Cores Pneumatic Wire Stripping Machine Semi Auto 49kg-115kg Force

Product Details:

Place of Origin: CHINA
Brand Name: CHENXIN
Certification: ISO90001
Model Number: CX-310

Payment & Shipping Terms:

Minimum Order Quantity: 2/Set
Price: Fob Shenzhen
Packaging Details: boxes
Delivery Time: 5-8 working days
Payment Terms: T/T
Supply Ability: 500 sets per month
Get Best Price Contact Now

Detail Information

Stroke: 100mm Stripping Length: 15mm
Voltage: AC 220v 50/60hz Air Pressure: 3-7kg/cm²
Stripping Force: 49-115kg Cylinder φ: 50φ
Weight: 25kg Dimension: 480mm*330mm*280mm
High Light:

CX310 Pneumatic Wire Stripping Machine

,

115kg Pneumatic Wire Stripping Machine

,

49kg pneumatic wire stripper

Product Description

CX-310 Semi Auto Pneumatic Mult Cores Sheathed Wire Cable Stripping Machine



Features:

1 The oblique back design is ergonomic.

2 Double-acting cylinder, no spring break.

3 Exquisite knife molds, large and small machine types, and knife and molds are universal.

4 Unique sliding seat, light and agile, easy to work.

5  Adjustable structure, adjusted according to the thickness of the wire.

6 Adaptable wire: AC, DC power cord, computer wire, electronic wire, multi-core wire, special wire.

7  Stable sliding seat design, unique sliding seat design ensures more stable stroke and more precise cutting and stripping.

8  The foot pedal is easy to operate. Improved the traditional computer wire stripping method with feet and hands, and evolved into a front clamp back method, which saves energy and improves efficiency.



Technical Parameter:

Model CX-305 CX-310 CX-315 CX-320 CX-330 CX-416
Stroke 50mm 100mm 150mm 200mm 330mm 150mm
Wire φ 5mm-7mm Max.15mm Max.20mm Max.20mm Max.20mm Max.30mm
Voltage  220V 60Hz 220V 60Hz​ 220V 60Hz​ 220V 60Hz​ 220V 60Hz​ 220V 60Hz​
Air pressure 3-7kg/cm² 3-7kg/cm²​ 3-7kg/cm²​ 3-7kg/cm²​ 3-7kg/cm²​ 3-7kg/cm²​
Stripping force 31-73kg 49-115kg 84-196kg 84-196kg​ 84-196kg​ 165-300kg
Cylinder φ 40φ 50φ 50φ​ 50φ​ 50φ​ 80φ​
Weight 20kg 25kg​ 35kg​ 50kg​ 65kg​ 50kg​
Dimension(mm) 400*300*270 480*330*280 660*390*340 700*400*360 1,100*550*450 615*425*375

Multiple Cores Pneumatic Wire Stripping Machine Semi Auto 49kg-115kg Force 0

 Selected high-quality blades, using high-quality wear-resistant blades, durable and long-lasting sharpness

Multiple Cores Pneumatic Wire Stripping Machine Semi Auto 49kg-115kg Force 1

Air pressure regulating valve, cut off the gas, and open the gas regulating valve.

Function: When adjusting the machine, the air pressure can be turned off to prevent hand injury and play a protective role.

Multiple Cores Pneumatic Wire Stripping Machine Semi Auto 49kg-115kg Force 2Multiple Cores Pneumatic Wire Stripping Machine Semi Auto 49kg-115kg Force 3
