CX 5 Cable Wire Terminal Crimping Machine 1.0mm To 2.54mm Terminal

CX 5 Cable Wire Terminal Crimping Machine 1.0mm To 2.54mm Terminal

Product Details:

Place of Origin: CHINA
Brand Name: CHENXIN
Certification: ISO90001
Model Number: CX-03

Payment & Shipping Terms:

Minimum Order Quantity: 1/Set
Price: Fob Shenzhen
Packaging Details: wooden case
Delivery Time: 10-15 working days
Payment Terms: T/T
Supply Ability: 150 sets per month
Get Best Price Contact Now

Detail Information

Cutting Length: 40mm-1,000mm(maxmum 2,000 Can Be Customized) Adaptable Wire: AWG#30-AWG#18
Adaptable Terminal: 1.0/1.25/1.5/2.0/2.54/3.96 Horizontal And Straight Mold Can Be Sharable Capacity: 5,500pcs-6,000pcs/hr(with Length 40mm-200mm)
Stripping Length: A, B Side 0-7mm Cutting Accuracy: ±(0.2%*L+1)mm
Air Pressure: 0.5-0.7Mpa(5-7kg/m³)
High Light:

CX 1.0mm Wire Terminal Crimping Machine

,

CX 2.54mm Wire Terminal Crimping Machine

,

40mm 5 Cable Crimping Machine

Product Description

CX-03 Full Automatic Double-end 5 Cable Wire Cutting Stripping Terminal Crimping Machine



Equipment Function:

Name of the machine CX-03 Full Automatic Double-end 5 Cable Wire Cutting Stripping Terminal Crimping Machine
Function

A, B side cutting, stripping, crimping

Control Method HMI+Microcomputer
Detection Device With terminal or not, No wires alarm, air pressure detection
Terminal pressure detection system Optional installation (applicable for domestic and imported systems)
Suitable mold OTP standard horizontal, straight mold
Crimping force 2T/3T Super mute terminal crimping machine



Technical Parameter

Voltage 50/60Hz 220V single-phase
Cutting Length 40mm-1,000mm(maxmum 2,000 can be customized)
Applicable cable AWG#30-AWG#18
Applicable terminal 1.0/1.25/1.5/2.0/2.54/3.96 horizontal and straight mold can be sharable
Capacity

5,500pcs-6,000pcs/hr(with length 40mm-200mm)

Stripping Length A, B side 0-7mm
Cutting accuracy ±(0.2%*L+1)mm
Air Pressure 0.5-0.7Mpa(5-7kg/m³)
Dimension 1,650mm*1,150mm*1,450mm;
Weight about 850kg±15kg



Device Configuration

Motor 5 sets of Japan Mitsubishi servo motors + 2 sets step motors
Pneumatic Components 12 sets of SMC electromagnetic valve + 11 sets of SMC Cylinder+adjusting device 8 sets
slide 10 sets of Taiwan Hiwin
Sensor Japanese Panasonic
Belt American Gates Brand
Bearing Japnese NSK
Blades it is made of imported alloy steel, processed by slow-moving wire, precision ground, and durable

CX 5 Cable Wire Terminal Crimping Machine 1.0mm To 2.54mm Terminal 0CX 5 Cable Wire Terminal Crimping Machine 1.0mm To 2.54mm Terminal 1CX 5 Cable Wire Terminal Crimping Machine 1.0mm To 2.54mm Terminal 2CX 5 Cable Wire Terminal Crimping Machine 1.0mm To 2.54mm Terminal 3
